At the beginning of 2024, I replaced a fragile VPN setup with WireGuard for site-to-site connectivity between my homelab and VPS network. The migration looked simple on paper, but reliability required more than just generating keys and bringing interfaces up.

Pexels stock photo: network cabling

Stock photo source: Pexels , image reference: photo 2881229 .

What I needed from the tunnel

The design goals were practical:

  • stable private connectivity for services and backups,
  • minimal operational overhead,
  • deterministic fail behavior,
  • enough throughput for nightly sync jobs,
  • tight network exposure boundaries.

I did not need a full mesh with dynamic control plane. I needed a dependable, understandable tunnel.

Topology choice

I built a hub-and-spoke model:

  • VPS edge node as hub,
  • homelab gateway as spoke,
  • optional mobile admin peer with restricted routes.

This kept routing policy centralized while limiting blast radius.

Baseline config pattern

On each peer, I used small explicit configs with strict AllowedIPs.

# /etc/wireguard/wg0.conf
[Interface]
Address = 10.90.0.2/24
PrivateKey = <private-key>
ListenPort = 51820

[Peer]
PublicKey = <hub-public-key>
Endpoint = vpn.gaborl.hu:51820
AllowedIPs = 10.90.0.0/24, 10.20.0.0/24
PersistentKeepalive = 25

Limiting AllowedIPs reduced accidental route leaks and simplified troubleshooting.

Routing and firewall integration

The tunnel only solved encryption. I still needed routing and filtering discipline.

I used:

  • policy-based routing for selected internal networks,
  • explicit nftables rules for tunnel ingress/egress,
  • default-drop policy with tightly scoped accept rules.

This prevented the common mistake of “VPN is up, but policy is unclear.”

MTU tuning lessons

My first rollout had intermittent packet loss on large transfers. Root cause was MTU mismatch across uplink path.

I fixed it by:

  • testing path MTU explicitly,
  • lowering WireGuard interface MTU,
  • validating throughput and retransmit behavior under load.

After tuning, transfer stability improved immediately.

Key rotation and peer lifecycle

I documented peer lifecycle with clear states:

  • provisioned,
  • active,
  • paused,
  • revoked.

Key rotation happened quarterly for critical peers. Revoked peers were removed from config and firewall allowlists in the same change window.

Observability and health checks

I exposed tunnel health via:

  • handshake age monitoring,
  • peer transfer counters,
  • packet error trend tracking,
  • route reachability probes.

One simple alert on stale handshake age caught most real outages quickly.

Incident that shaped the final setup

A home ISP endpoint IP change broke connectivity at 03:00. The tunnel did not recover automatically because DNS caching on one node was stale.

Fixes:

  • lowered DNS TTL for tunnel endpoint,
  • added periodic endpoint re-resolution,
  • created auto-remediation script for stale peer endpoint.

This made future endpoint changes effectively non-events.

Security hardening changes

I added:

  • narrow management access only over VPN,
  • per-peer route restrictions,
  • split admin and service peers,
  • audit logging for firewall and route changes.

I also removed legacy SSH exposure from public interfaces wherever VPN access was sufficient.

Outcomes after rollout

  • tunnel uptime improved significantly,
  • backup job success rate increased,
  • remote maintenance became predictable,
  • incident resolution time dropped because visibility was better.

The highest-value gain was confidence during off-hours maintenance.

Mistakes to avoid

  1. Over-broad AllowedIPs that hide route mistakes.
  2. Ignoring MTU path behavior.
  3. Treating key management as one-time setup.
  4. Running tunnel without basic health metrics.
  5. Mixing admin and service traffic without policy boundaries.

Final takeaway

WireGuard was fast to deploy, but reliability came from network discipline around it: routing, firewall policy, key lifecycle, and observability. Once those were in place, secure connectivity became boring and dependable, which was exactly the goal.
